Delphi tutorial: serial comms, i.e. using the COM port
Bi-directional Communications
Hyperterminal derivative
This has good information, and a search button at the bottom of the page
Please don't dismiss it because it isn't full of graphics, scripts, cookies, etc!
This page is crude.. sorry.. Please don't judge my general postings based on this sub-standard example.
WARNING..
I am old fashioned. I disavow any responsibility for things you may elect to do. In particular, I disavow any responsibility for any consequences arising from connections you make between devices. You can't just plug 'anything' into your computer or anything else!. In particular, make sure that you aren't assuming that an RS-232 interface can be connected directly to, say, an Arduino or BASICstamp, or PIC or other microprocessor. There are notes on some of those issues on my serial ports page, for those of you who need them.
Enough 'lawyer feeding'.. let's turn to the Fun Stuff..
If you have already read my page 'dt4t' (the illustrations just a little way down the page will be familiar), you can jump ahead to material HERE that isn't duplicated THERE!
This is one in a series of tutorials which show you how to link two devices using serial comms. In the tutorials, the 'devices' are a Windows PC running programs written with Delphi and an Arduino.. neat little, inexpensive, fun, capable microprocessor. However: Either device could be replaced by another.. many of the issues discussed here are general, but I find that principles are best understood when backed up by examples of their application.
Click here if you want to know more about the sourceand format of these pages. It may be easier to read this if you re-size the window, so that it does not use the full width of your screen.
The Delphi sourcecode is available for download. The Arduino sourcecode is presented here in full, and you can copy it and paste it into your Arduino development environment for compilation and upload to your Arduino.
These pages are ROUGH and ILL-EDITED at this time. Explanations are sketchy. But the code DOES work. If this note is still here 15 September 2010, write and complain!
Two computers; one system
For many years, for a number of different reasons, I've wanted to hook a microprocessor to a 'big' computer, and have them talk to one another. These days (August 2010) I am using the wonderful Arduino for microprocessor projects, and a Windows XP computer for my 'main' work. The material below could be used with other devices. In particular, if your objective is to connect some serial device to a 'big' PC, you will find helpful material, I hope.
In the diagram below, if you assume that the 'some serial device' is a PC, you see two PCs attached to the Arduino. The one on the left is there for when you are setting up the Arduino to do whatever you want it to do with the other PC. It would normally unplugged, taken away after the system had been built.
The set up above is pretty general. Even without restricting what it implies, you can have two scenarios.
In order to explain the scenarios, I need to say what I mean by 'Master' and 'Slave' in the rest of this essay. A 'master' device is in charge. The 'slave' device will 'speak when spoken to'. It may get on with various things when it isn't commanded by the master to be doing other things, but it will not 'come up' on the serial channel, aka 'serial link' between master and slave unless the master has told it to. The master may 'speak' to the slave in an imperious manner, just issuing a command, and assuming the slave will execute it without any reply. If, for instance, there was an LED attached to the slave, the master might send a 'turn LED on' command'. Or, the master might 'say' 'Turn on the LED, and tell me that you've done it.' In the latter case, the master would have to be programmed to look for the slave's reply.
You can build systems like the above in which the 'Some Serial Device' is the master, and the Arduino is the slave, and you can build systems the other way around (Arduino as master, other serial device as slave.) In the work so far within this tutorial, an example of a Windows XP computer as master, with an Arduino as slave has been created. (The hard parts of doing the reverse are all solved, and part of the first solution.)
Serial Communication Arduino To Pi
It is all well and good thinking in general terms, but eventually it is necessary to get down to cases. For the work to be discussed, this is the set-up I was using..
The Wulfden module is a neat, inexpensive solution to the problems arising from the fact that the PC uses RS-232 serial comms and the Arduino is a TLL device. I'll try to expand on that later. (See my serial port page, for a badly written 'answer', in the meantime.('Hardware' section, near top.)) N.B.: The 'Rx'/'Tx' markings on the device, and on the diagram above cause people no end of confusion. They stand for 'transmit' and 'receive'.. but relative to which device??? There's a signal FROM the PC TO the Arduino that is marked 'Tx' above. and we are transmitting from the PC to the Arduino.. but the Arduino might well call that line 'Rx', as it is the line the Arduino is receiving on. Not rocket science, but easy to get turned around. Follow the diagram: Connect the signal marked 'Tx' on the PA4B to digital pin '3' of the Arduino, the signal marked 'Rx' on the PA4B to digital pin '4' of the Arduino, enter the Arduino programs given below, and all will be well.
I suppose this is the place to say something about the connection from the PC running the Arduino Development Environment to the Arduino. It goes to digital pins 0 and 1. I'm not doing anything 'clever' here.. that's just the normal connection, over which you send programs ('sketches') to the Arduino from the PC where they are compiled.
Apologies for that little diversion. The problems this tutorial sets about solving are rife with 'little details', all of which have to be Got Right.
